SMA Female to Female Bulkhead Hermetic Adapter
P/N: SF2991-6002

There currently isn't any inventory available in distribution. Please contact us to obtain this product.

Products specifications

Attribute name	Attribute value
RF Series	SMA
Orientation (Body)	Straight
Gender	Jack (Female)
Coupling	Threaded
Mounting Type	Panel
Style	Hermetic
Body Style	Jamnut/Bulkhead
IP Rating	IP 68
Finish	Passivated
RF Series 2	SMA
Gender 2	Jack (Female)
Orientation 2 (Body)	Straight
Electrical
Impedance	50 ohms
Frequency	18 GHz
Dielectric withstanding Voltage	1000 VRMS
Shielding Effectiveness	≥ -90 dB
Mechanical
Intermateability	2.92mm
Mating Torque	7 - 10 in - lbs
Mating Cycles	500
Environmental
Temperature Rating	-65°C to +165°C
Corrosion (salt spray)	MIL-STD-202, Method 101, Condition B
Vibration	MIL-STD-202, Method 204, Condition D
Shock	MIL-STD-202, Method 213, Condition I
Moisture Resistance	MIL-STD-202, Method 106, Less Step 7B
Thermal Shock	MIL-STD-202, Method 107, Condition B
Barometric Pressure (Altitude)	MIL-STD-202, Method 105, Condition C, 70k Ft.
